Glaval Concorde

Glaval Concorde

The flagship bus in the Glaval line of buses is the Glaval Concorde II. The engineering on the this bus will impress even the most savvy bus shopper. The medium duty chassis can be configured to carry up to 50 passengers including the driver. The Glaval Concorde II can be built on either the Ford F-65o or the F-750 chassis, both of which are super rugged and super reliable due to the Cummins™ engine inside. To go with the strong engine, the Concorde II uses the Allison transmission as its transmission of choice. The bus also boasts 22.5″ wheels to create a ride that is only rivaled by over the road coaches.

Another feature that helps to improve performance is the front end of the bus. The aerodynamically styled front end features a beautiful front upper panoramic window which allows passengers in the front of the bus great views. As with the rest of the buses in the Glaval stable of buses, the Concorde II features a durable steel cage construction. If you need to carry a very large group of people, the Glaval Concorde II deserves a good look.




Glaval Concorde II Standard Conversion Features

  • “Steel-Safe” Constructed Floor, Roof and Sidewalls
  • Galvanized Steel Floor Frame
  • Galvanized Steel Stepwell
  • Galvanized, All Structure
  • 5/8″ Treated Marine Grade Plywood Flooring
  • Gray Koroseal Commercial Flooring w/Ribbed Aisle Cove Molding
  • Vacuum Laminated Construction, Side and Rear
  • Fiberglass Front Cap & 5-Piece ABS Rear Cap
  • Fiberglass Composite Roof
  • Frameless Bonded Windows includes Full Blackout Paint
  • Electric Panel w/Diagnostic Fuses
  • Exterior Heated Remote Mirrors
  • Flat Floor
  • LED Stepwell Lights
  • Vinyl Clad Lauan Ceiling & Interior Sidewalls
  • Track Seating
  • Curb side Entrance Modesty Panel & Stanchion
  • All Exterior LED Lighting
  • Rear Center Brake Light (LED)
  • Rear Mud Shield
  • Steel Rear Bumper (Powder Coated)
  • Window Drip Rails
  • Exterior Rub Rails
  • White Exterior
  • Foamed In-place Roof Insulation
  • Front End Alignment (Toe-In, Toe Out)
  • Under-Coating with Warranty
    **5 year/100,000 mile limited conversion warranty. Specifications and options are subject to change without notice.

Glaval Concorde II Chassis Specifications

  • Chassis: Ford F-650
  • Cab Seating: Standard Driver’s and Co-Pilot Seating
  • Drivers Seat: Standard Air-Ride High-Back Gray Cloth w/Arm Rest
  • Engine: Cummins 6.7L Diesel
  • Engine Rating: 240 hp; 560 lb-ft torque
  • GVWR: 25,999
  • Alternator: 320 Amp
  • Fuel Tank: 65 Gallon
  • Alternative Fuel: B-20 “Bio-Diesel” capable
  • Urea DEF Tank: 5-Gallon
  • Transmission: Allison 2200 PTS 5-Speed w/Park Pawl
  • Brake System: Hydraulic ‘Quadraulic Split’ 4-Channel ABS
  • Parking Brake: Bosch DSSA Type 12 x 3. Orsceln Lever
  • Wipers: Standard Intermittent
  • Battery: Dual 900 CCA Batteries (1800 CCA Total)
  • Cruise Control: Standard Electronic
  • Fast Idle: Standard
  • Steering: Power w/Tilt Steering Wheel
  • Wheels: 22.5″ x 7.5″ Powder Coated Steel 10-Hole w/Dual Rear
  • Tires: Michelin XZE 235/80R22.5G (555 rev/mile)
  • Stereo: Standard AM/FM/CD & Clock
  • Speakers: Standard 8 Total (includes cab area)
  • Tow Hooks: Standard Front Frame Mounted
  • Air System: Cummins 18.7 CFM (Includes Guage)
  • Hood: Full Easy Tilt
  • Air Drain Valve: Bendix DV-2 Automatic w/Heater
  • Rear Axle Ratio: 5.29 to 1
  • Front Axle Rating: 10,000 lb Dana I-Beam Type
  • Front Spring: 10,000 lb Taper Leaf
  • Rear Axle Rating: 19,000 lb Meritor Single-Speed
  • Rear Spring: 18,500 lb Air-Ride w/Leveling Valve
  • Auxillary Power: 12-Volt In-Dash
  • Front Bumper and Grill: OEM Chrome
  • Engine Block Heater: Standard 120 Volt/750 Watt Phillips
  • Headlights: Halogen Lamp
  • License Plate Holder: Standard Front and Rear

Glaval Concorde II Model Specifications

  • Wheelbase: 240″, 260″, 281″
  • Overall Length: 30′, 32′, 34′, 36′, 38′, 40′ (Bumper to Bumper)
    (Optional 43′ w/F750)
  • Overall Width: 96″ (Optional 102″)
  • Overall Height: Approximately 128″ (Overall height can vary based on bus length, wheelbase and option content)
  • Front Overhang: 50″
  • Interior Height: 78-1/2″
  • Interior Width: 92″ (98″ wide option available)
  • Interior Floor Height From Ground: 43-1/2″
  • Entry Door Dimensions: 30″ x 87″ (clear opening)
  • Aisle Width: 18″
  • Clear Door Opening: 30″
  • Ground to First Step: 14″
  • Step Riser: 9-3⁄8″
  • Step Tread: 10″
  • Step Width: 34″

Glaval Concorde II Paratransit Options

  • ADA Lighting (Lift and Door)
  • ADA Signs
  • Double Doors (Lift)
  • Belt Storage Box
  • Interlock System
  • Padding Kit
  • Surelok/Qstraint Tiedowns
  • Lift Package, Braun
  • Lift Package, Maxon
  • Lift Package, Ricon

**Lift Package Includes: Single Door; Lift; Park Interlock; ADA Signs; Door Activated Lift and Entrance Lighting, Rear Exhaust (Rear or Roadside Exhaust Required on Rear Lift Models.)
